DS-PAD Mainboard

{gallery}45{/gallery}

DS-AD68 Mainboard

Product Features

  • Integrated LVDS/EDP/HDMI OUT and other display functions, with the maximum support of 4K decoding of 3840x2160.
  • Rich extension interface. Five USB ports (5 pins, one for OTG), and an extensible serial port.
  • Support Android system customization, provide system call interface API reference code, perfect support for client application development.
  • Perfect support for infrared, capacitive touch and other mainstream touch screens, support the free - drive touch screen of HID configuration, no debugging.

DS-AD68 Mainboard, DS-PAD Mainboard

DS-AD68 is the latest high performance universal motherboard based on rk3368. RK3368 uses the 8 cores 64 bit cortex - a53 architecture, the highest frequency is up to 1.5 GHz, and GPU uses PowerVRG6110. It is one of the very good processors in the market at present. The motherboard is integrated with an extended interface. It is widely used in the field of commercial display.

QXW-D68 Mainboard


DS-AD68 motherboard applications

It is applicable to interactive client, media broadcast, advertisement, information system, digital signage, intelligent device, smart medical, security, etc

QXW-D68 Mainboard Application field


Main Hardware Indexes

Model DS-AD68
Size 115*78mm
OS Android 6.0 or up
CPU RK3368,eight Cortex-A53,frequency up to 1.5 GHz
GPU PowerVR G6110
RAM Support 1GB/2GB (optional)
ROM EMMC 8GB/16GB/32GB(optional)
Network 3G、Ethernet、Wifi、 Bluetooth4.0
USB 1X USB OTG 4X USB HOST
Serial 1 rs232 connector
Wireless WIFI,BT4.2
Ethernet 10M/100M Ethernet
External Storage/td>  Support 32GB SD card
LVDS Single channel ,up to 1366×768
eDP Support,up to 2K
HDMI Support HDMI2.0,up to 1080P@120Hz,4kx2k@60Hz
Video Decoding Up to 3840*2160
Video format Support wmv、avi、flv、rm、rmvb、mpeg 、ts、mp4
Image format Support BMP、JPEG、PNG、GIF
Audio Support left and right channel
RTC Support
Alarm Support
Watchdog Support
IR Support
System upgrade Support TF,USB,OTA
