New Retail POS Mainboard

{gallery}48{/gallery}

NR-P68 Mainboard

Product Features

  • Multiple display functions such as integrated single, double LVDS/EDP/HDMI OUT, and the maximum support of 4K decoding of 3840x2160.
  • The built-in pci-e 3G module supports various pci-e 3G / 4G modules such as huawei, zte and longshang.
  • Rich extension interface. 8 USB ports (2 board with USB2.0, 4 pins USB2.0, 2 OTG ports), 4 extendable serial ports.
  • Support Android system customization, provide system call interface API reference code, perfect support for client application development.
  • Perfect support for infrared, capacitive touch and other mainstream touch screens, support the free - drive touch screen of HID configuration, no debugging.

NR-P68 mainboard, leading the new retail trend

NR-P68 is the latest high performance universal motherboard based on rk3368. RK3368 uses the 8 cores 64 bit cortex - a53 architecture, the highest frequency is up to 1.5 GHz, and GPU uses PowerVRG6110. It is one of the very good processors in the market at present. The motherboard is integrated with an extended interface. It is widely used in the field of POS.

New Retail POS NR-P68  Mainboard


NR-P68 Mainboard, Application Field

It is suitable for many kinds of payment industries such as supermarket, high street, sweet shop, hair shop, coffee shop and catering

NR-P68 Mainboard Application Field


Main Hardware Indexes

Model NR-P68
Size 120*118mm
OS Android 6.0 or up
CPU RK3368,eight Cortex-A53,frequency up to 1.5 GHz
GPU PowerVR G6110
RAM Support 1GB/2GB (optional)
ROM EMMC 8GB/16GB/32GB(optional)
Network 3G/4G、Ethernet、Wifi、 Bluetooth4.0
USB 1X USB OTG ,6X USB HOST
Serial 1 rs232 connector
Wireless WIFI,BT4.2
Mobile network Support 3G/4G
Ethernet 10M/100M Ethernet
External Storage  Support 32GB SD card
LVDS Single channel ,up to 1366×768
eDP Support,up to 2K
HDMI Support HDMI2.0,up to 1080P@120Hz,4kx2k@60Hz
Video Decoding Up to 3840*2160
Video format Support wmv、avi、flv、rm、rmvb、mpeg 、ts、mp4
Image format Support BMP、JPEG、PNG、GIF
Audio Support left and right channel
RTC Support
Alarm Support
Watchdog Support
IR Support
System upgrade Support TF,USB,OTA
